• Transmission electron microscopes (TEM)

Transmission electron microscopes (TEM)

Transmission electron microscopes (TEM)


Instrument introduction:

1. Brand type:
Japan JEOL JEM 2100PLUS (using 200KV)
Japan JEOL JEM 1230 (using 100KV)


2. Main functions:

Japan JEOL JEM 2100PLUS
1. Accelerating voltage: 80 – 200 kV
2. Lamp silk: LaB6
3. Resolving power: point image 0.27 nm
4. Magnification: 1,000 – 1,000,000
5. Image capture: film (4 * 3.25 inches)+CCD-Camera(Gatan OneView)
6. EDS (OXFORD INCA X-MAXN)
7. Shot Meister software

Japan JEOL JEM 1230
1. Accelerating voltage: 40 – 120 kV
2. Lamp silk: LaB6
3. Resolving power: point image 0.36nm
4. Magnification: 1,200 – 600,000
5. Image capture: film (4 * 3.25 inches)+CCD-Camera(Gatan 832)



Placement:
"Microscope Center", Room 0459, Area B, 4th Floor, First Medical Building.

Opening hours:
Monday to Friday AM 8:30～PM 5:00

Application principles:

A. Equipment Booking:
1. Please visit the Microscope Center website to register and book your usage time, and operate the equipment as scheduled.
2. If admin assistance is required, confirm the operating time with the admin after booking on the website. Charges will be based on the booking time recorded on the website.

B. Those who board the plane by themselves:
1. Technical Appraisal: Make an appointment with the contact person of the center for practice time, and further accept the operational appraisal.
2. Technical appraisal standards:
a. Understanding of the working principle of the machine.
b. Preparation work before start-up (starting voltage, work record inquiry, sample requirements, etc.).
c. Test items after startup (pressure, pump, vacuum, machine condition test, etc.).
d. The relationship between software and machines.
e. Restore various settings before shutting down and accurately record the usage status.
f. Troubleshooting.

C. Specimen preparation requirements:
1. Please place the sample on a copper grid with a diameter of 3 mm.
2. In order to maintain the vacuum, the sample must not have characteristics that will decompose, release gas or become liquid under electron beam irradiation.
3. To avoid damage, this instrument refuses to accept powder-type samples or materials that have strong magnetism, magnetism (such as iron, cobalt, nickel, etc.) or are easily attracted by electromagnetic lenses.
4. To avoid damage, this instrument refuses to accept samples containing toxic, corrosive, volatile, and low melting points.
5. To avoid instrument and computer poisoning, please use a CD to burn electronic files.

D. Notes:
1. If you do not get on the plane for 1 hour after the scheduled time, the center may arrange this time for other people who need to get on the plane. If you find that there is a problem with the experiment and you are unable to board the machine, please cancel the reservation, otherwise the reservation period will be charged according to the price.
2. Anyone who violates the usage regulations three times will be disqualified and will not be allowed to apply again within six months.
3. The experimental results provided by our center are for academic research reference only and we do not assume any legal responsibility.
4. The above usage and charging methods will be revised according to the situation. The actual situation will be subject to the online announcement.
5. Turn on and off the machine: Please follow the correct procedure.
6. Data backup:
(1) Users should save the experimental data immediately after each experiment.
(2) The administrator removes user data from the computer every six months.

E paper publication and statement:
1. The services of this Microscopy Center are mainly academic research. Anyone who applies to this laboratory for the listed services must be stated in the acknowledgment column of the article when the results are published.
2. If you cooperate with teachers of our school and sign a cooperation contract, the method of sharing the results will be in accordance with the content of the contract.

Charging principles:
1.Charge standard:
ˆ
JEOL JEM 2100PLUS
Fee items unit price (on campus) / unit price (off campus, no cooperation plan)
Instrument usage fee:  1200 NT/hour   /   not open yet
                                  (Unuse EDS)
                                 1500 NT/hour   /   not open yet
                                  (Use EDS)

JEOL JEM 1230
Fee items unit price (on campus) / unit price (off campus, no cooperation plan)
Instrument usage fee:  300 NT/hour   /   600 NT hour



Note: Charges are calculated based on the reservation time, and the part less than half an hour is calculated as half an hour. If the delay is caused by the former use, it will not be included.

2.Charging method:

Transfer payment: For research projects within the Chang Geng system, the research project leader should confirm, sign and stamp the fee schedule for the use of each instrument immediately upon receiving it, and then submit it to the accounting office of the center according to the plan. Case number transfer payment.

Cash payment: For research projects that are not under the Chang Gung Memorial System, payment will be made to the cashier of the school according to the payment slip issued by each instrument contact person. If a receipt is required, the payment will be issued at the accounting office.

Contact person:
Miss Hwei-Chung Liu ; Miss Wan-Zhen He
Tel: (03)211-8800 ext. 5065; E-mail: monica@mail.cgu.edu.tw ; D000014932@cgu.edu.tw

---
